HMAS New South Wales (BB-1915 (ex-Canada))



Back to Commonwealth Ships List



I always retain the ex Canada for the Commonwealth navies. It is too good a partner for the fast carriers to let it go back to Chile. In place of Canada (& Eagle or money) I give the Chileans the 3 remaining ships of the King George V class completed in 1912/13 and an Invincible class BC with some light cruisers of the same vintage and either L or M class destroyers to go with the Botha class leaders. This gives Chile a force to be reckoned with and binds the Chileans to the UK sphere of influence.

HMS Canada was purchased from the Royal Navy to partner the other 14" ships in Australis service, (HMAS Australis, HMAS Queensland). This gave Australis a nice set of matched squadrons. Three Queen class (8x15"), three 14" BB/BC's and the four 13.5" BB/BC's. The ship arrived in Australis waters in 1924 and was commissioned into the Australis Navy as HMAS New South Wales.



Canada's biggest problem was the side armour. A belt armour of 9 inches put it in the battlecruiser class of armour. The easiest answer to this was to replace it with the 11 inch armour removed from the Australis Neptune class ex-battleships when they were converted to training ships/ADV's. The 9 inch belt being placed above the 11 inch belt.

HMS Canada as originally completed.



This re-armouring took place during the 1937-39 rebuilding that the older battleships went through during the 1930’s. New superstructure, new engines (changed from coal to oil firing), newish side armour, new deck armour, new dual purpose secondary armament, replaced the old broadside 6 inch guns which were plated over, the removal of  Q 14 inch turret, new bow structure. All these changes gave the ship a complete new look. The Australis ship New South Wales (ex Canada) had the largest rebuilding undertaken by the Australis Navy.





Displacement 25,000 tons standard, 32,000 tons full load 28,000 tons standard, 34,890 tons full load
Length 661 feet 705 feet after rebuilding
Breadth 93 feet (105 feet over bulges)
Draught 32 feet
Machinery 4 shaft, steam turbines, 40,000shp geared turbines, 4 shafts, 130,000shp
Speed 23 knots 29 knots
Armour 9" belt, 1.5" deck, 10" turrets 11”-9” side, 5” deck, 10"/7"/5" turrets
Armament As completed
8 x 14” (4x2)
16 x 6” (16x1)
2 x 3" AA (2x1)
4 x 2pd (4x1)
As rebuilt to 1941
8 x 14” (4x2)
20 x 4.5” (10x2)
48 x 2pd (6x8)
20 x 20mm (20x1)
Aircraft nil 3
Torpedoes 4 x 21" submerged nil
Complement 920 1140 as flagship
Notes: HMAS New South Wales (ex Canada) 10/1915.




Previous drawings of the Canada.


As the ship is to be paired with Eagle on operations the aircraft handling facilities were never fitted, the hangar area being used as extra offices and accommodation for the extra staff that being a fleet flagship entailed. The catapult area was built in and used for the ships boats.

In that other Universe the Canada was returned to Chile in 1920 and spent the next 40 years with little alteration.
